Getting Started
ENGLISH
a Control Lever (੬ 6)
: Left / Rewind [
3
] (੬ 16) /
Quick Review [QUICK REVIEW] (੬ 14)
: Right / Fast-Forward [
5
] (੬ 16)
: Up / Play / Pause [4/9] (੬ 16) /
Manual Focus [FOCUS] (੬ 23)
:Down / Stop [8] (੬ 16) /
Backlight Compensation (੬ 25) /
Spot Exposure (੬ 25)
Press down: SET
B Menu Button [MENU] (੬ 18)
C Auto Button [AUTO] (੬ 15)
D Data Battery Button [DATA] (੬ 12)
E Recording Start/Stop Button (੬ 14)
F Zoom Lever [T/W] (੬ 16) /
Speaker Volume Control [VOL. +, –] (੬ 16)
G Power Switch [REC, OFF, PLAY]
H Lock Button
I Cassette Open/Eject Switch [OPEN/EJECT]
(੬ 13)
J Battery Release Button [BATT.] (੬ 11)
K 16:9 Wide Screen Button [16:9] (੬ 13) /
Blank Search [BLANK] (੬ 17)
L Snapshot Button [SNAPSHOT] (੬ 23)
M S-Video Output Connector [S] (੬ 28)
N Digital Video Connector [IN/OUT] (i.LINK*)
(੬ 29, 30)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.LINK
standard.
The connectors are located beneath the cover.
O Audio/Video Output Connector [AV] (੬ 28)
P DC Input Connector [DC] (੬ 28)
Q POWER/CHARGE Lamp (੬ 11)
R LCD Monitor (੬ 8)
S Shoulder Strap Eyelet (੬ 7)
T Grip Strap (੬ 7)
U Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here)
V Stereo Microphone
W Lens
X Speaker (੬ 16)
Y Cassette Holder Cover (੬ 13)
Z Stud Hole (੬ 7)
a Tripod Mounting Socket (੬ 7)
b Battery Pack Mount
c Connector Cover
Controls
Connectors
Indicator
Other Parts
Power Switch Position
REC:
To perform recording on the tape.
OFF:
To switch off the camcorder.
PLAY:
To play back a recording on the tape.
Set the power switch while
pressing down the lock button.
