13
ENGLISH
Camera
Touch Sensor (੬ pg. 6)
OK (DISP) Button [OK/DISP] (੬ pg. 15)
Menu Button [MENU]
Power Switch [POWER]
(You can turn off the camera by pressing
and holding this button.)
Speaker
Playback/Recording Mode Switching
Button [SELECT PLAY/REC] (੬ pg. 20)
Access/Charge Lamp [ACCESS/CHARGE]
(Blinks when you access fi les or charge
the battery. Do not turn off the power or
remove the battery pack/AC adapter while
accessing fi les.)
Direct DVD Button [DIRECT DVD]
(੬ pg. 43)/Title Button [TITLE] (੬ pg. 37)
Direct Backup Button [DIRECT BACK
UP] (੬ pg. 52)/Information Button [INFO]
(੬ pg. 33)
Auto/Manual Mode Button [AUTO/
MANUAL] (੬ pg. 24)
Video Recording Start/Stop Button [START/
STOP] (੬ pg. 20)
Still Image Shooting Button [SNAPSHOT]
(੬ pg. 21)
Zoom Lever [W
, T ] (੬ pg. 22)
Speaker Volume Control [–VOL+]
(੬ pg. 27)
Mode Switch [
, ]
DC Jack [DC] (੬ pg. 16)
Audio/Video Jack [AV]
USB (Universal Serial Bus) Jack [
]
(੬ pg. 40, 42, 51 and 58)
Camera Sensor
Lens Cover (੬ pg. 18)
Lens
Lens Cover Switch [
, ] (੬ pg. 18)
Stereo Microphone
microSD Card Slot (੬ pg. 19)
Stud Hole (੬ pg. 18)
Tripod Mounting Socket (੬ pg. 18)
Battery Release Button [BATT.] (੬ pg. 16)
Battery Pack Mount (੬ pg. 16)
Grip Strap (੬ pg. 18)
