- 30 -
Selecting Band
Band, can be chosen either,
C or S by or button.
Selecting Channel
Channel can be changed by
or button
or by Digit Buttons.
Selecting Colour System
Using or button on Colour System,
you can change the colour system to PAL,
SECAM or Auto.
Note: In EXT mode, you can choose NTSC
3.58 and NTSC 4.43 as well.
Selecting Sound System
Using
or button on Sound System,
you can change the standard to BG, DK, I, L,
Lp.
Selecting Fine Tuning
You can use the Fine Tuning process for fine
adjustment (after coarse adjustment), if you
are not happy about the image on the screen.
Use or button on Fine Tuning item,
until getting the best image on the screen.
Selecting Search
To start the search process, press button
for forward search or
button for backward
search. If a signal is found or reaches to end
of the band after searching, press
or
buttons to continue search process. To stop
the search process when you want, press
or buttons at any time.
Decoder (EXT-2)
You can use this mode to connect any de-
coder to your TV.
Press the or buttons to set it On or
Off.
When you select Decoder (EXT-2) On, EXT-2
output will be chosen as TV mode only and
any scrambled channels will be unscrambled
through decoder connected your TV via EXT-2
output.
Setting VCR ( Video Cassette Recorder )
Mode
This item can be seen in TV, EXT-1, EXT-2,
EXT-2S, EXT-3, EXT-4 and EXT-4S modes.
If you want to watch a VCR source from one
of these modes, then it will be better to set
VCR mode On. For this, while the cursor is
on this item press the
or buttons to
set it On.
If you want to watch a DVD, then you must set
this item off; because DVD is not a source
like a VCR and to see the picture better, you
must set the VCR mode Off.
To Store Settings
Press
/ or OK button on Store op-
tion to store Install menu settings.
After stored, T-V LINK menu will appear. If
you do not need to do T-V LINK, select Can-
cel and press or OK button to exit the
menu.
Program Menu
Press "MENU" button, now you are in main
menu. In the main menu, select Program
using
or button. Then enter the
Programme menu by pressing
/ or
OK button.
Note: There is no Program menu in any EXT
modes.
Program Menu is used to delete a channel, to
change the programme number of a channel,
to give a channel name to a channel, and to
start the A.P.S (Autostore) function.
