Learning about the printer
For additional setup and instructions on using the printer, see the User's Guide available on the Lexmark Web site at
http://support.lexmark.com.
Printer overview
The Lexmark
TM
Forms Printer 2500 Series printers are available in 9 and 24wire narrow and widecarriage models.
Depending on the model you have chosen, your printer may look slightly different from the printer illustrated.
Printer front view
A
2
3
4
5
6
7
8
1
Part name
1 Forms thickness lever
2 Ribbon access cover
3 Power switch
4 Paper select lever
5 Paper guides
6 Manual feeder
7 Front cover
8 Control panel
Learning about the printer 4
