Speed diagram:
65
Maximum torque occurs with a non-linear load as prevails under use in a leisure bed. That is to say large torque during
start, which lessens as the backrest is raised. This is also how the TD1 has been tested.
TWINDRIVE 1 - Speed
0,00
0,10
0,20
0,30
0,40
0,50
0,60
0,70
0,80
0,90
18 72 126 180 234 288
Torque [Nm]
Speed [Rpm]
Twindrive 280
Twindrive 220
220 Nm ~ 3500 N 280 Nm ~ 4500 N
Torque on testrig for Twindrive
220 Nm / 280 Nm
0
50
100
150
200
250
300
0 10203040506070
Degrees above horisontal [°]
Torque [Nm]
Twindrive 280
Twindrive 220
Speed curve for the TD1 analogue versions:
