Phoneline 10M USB Network Adapter
37
Customer Support
For help with the installation or operation of your HomeLink Phoneline 10M
USB Network Adapter, contact Linksys Technical Support at one of the
phone numbers or Internet addresses below.
Customer Support 800-326-7114
949-261-1288
Fax 949-261-8868
E-mail support@linksys.com
Web Site http://www.linksys.com
FTP Site ftp.linksys.com
Linksys HomeLink™ Series
36
Specifications
Model Number USB200HA
Standards HomePNA Version 2.0-Compatible,
USB Version 1.0 or higher
Protocol CSMA/CD
Ports 1 USB Type-B Port
2 Standard Modular RJ-11 Telephone Ports
With Pass-Through Feature
Speed 10Mbps or 1Mbps
Cabling Standard Copper Telephone Cable with RJ-11 tips
Topology Daisy Chain
Bus Speed 12Mbps (Buffered) Universal Serial Bus
LEDs Power, TX, Link, RX
Environmental Specifications
Dimensions 3.8" x 2.6" x 1.2" (97 mm x 66 mm x 30 mm)
Unit Weight 5.0 oz. (156 g)
Power 5V, Bus Powered from PC
Certifications FCC Class B, CE Mark Commercial
Operating Temperature 32ºF to 122ºF (0ºC to 49ºC)
Storage Temperature -4ºF to 158ºF (-20ºC to 70ºC)
Operating Humidity 10% to 85%, Non-Condensing
Storage Humidity 5% to 90%, Non-Condensing
