3. Press the AMP button and CD button. M1-
02 is displayed on the LCD.
Press the AMP.
↓
Press the CD.
4. Press the CD button and “3” button. M1-03
is displayed on the LCD.
Press the CD.
↓
Press the “3”.
5. Press the CD button and 2 button.
↓
6. When you are finished programming
the macro, press the ENTER button until
the MACRO indicator is disappeared and
returns to normal mode.
Now, execute the macro you just
programmed.
7. Press the MACRO button and “1” button.
• The macro commands are transmitted to
the components in order, and the steps
of the operations are displayed on the
LCD in order.
Note
When programing the amplifi er's input source in
the macro program, fi rst press the AMP button, and
press the source button.
(In the case of DVD input: AMP → CD)
EXAMPLE 2
Turn this unit’s power on
↓
Turn the DVD player’s power on
↓
Change this unit’s input source to DVD
↓
Set the DVD player to play
3.
3.
3.1.
2.
5.
3.1.
5.
4.
1. Press and hold the MACRO and SET buttons
until the LEARN, MACRO indicators and
MACRO are displayed blinking on the LCD.
2. Press the “2” button. M2-01 is displayed on
the LCD.
3.
To set the various steps of the macro, press
the following buttons in order:
(1) AMP → POWER ON.
↓
(2) DVD → POWER ON.
↓
(3) AMP → DVD.
↓
(4) DVD → PLAY.
↓
4. When you are finished programming
the macro, press the ENTER button until
MACRO indicator is disappeared on the
LCD and returns to normal mode.
Now, execute the macro you just
programmed.
5. Press the MACRO button and “2” button.
• The macro commands are transmitted to
the components in order, and the steps
of the operations are displayed on the
LCD in order.
