3
1 00002674 Open Spoon 1/2" 30 36 00012158 Flat Washer, 3/8, SAE, Yellow Zinc 11
2 00006131 Hex Nut, 3/8-16 65 37 00012168 Lock Washer, 5/16, Zinc 7
3 00006168 Flat Washer, USS 3/8 Zinc 4 38 00012171 HHCS, Standard, 3/8-16 x 1, Zinc 14
4 00006194 Lock Nut, Nylon Insert, #10-24 2 39 00012172 HHCS, Standard, 3/8-16 x 2, Zinc 1
5 00006246 Key, 3/16" x 1" 1 40 00012173 Lock Nut, Nylon Insert, 3/8-16 8
6 00006519 Idler, Flat 3616 1 41 00012178 HHCS, Standard, 5/16-18 x 1/2, Zinc 3
7 00008495 Capscrew, 3/8-16 x 1-3/4" 60 42 00012204 Cotter Pin, 3/32 x 3/4, Zinc 2
8 00008646 Bushing, Flange, Sintered, Bronze 2 43 00013311 Decal, Rotary “Danger-Keep Hands” 2
9 00008666 Cap Screw, Square Head, 5/16-18 x 2-1/2 1 44 00013433 Hex Nut, 5/16-18, Yellow 5
10 00008679 Rear, Wheel, 410/350 x 4-2Ply, White 2 45 00013733 Shoulder Bolt, Socket, 3/8 x 3/8 Zinc 1
11 00008700 Caster Wheel 2 46 00017633 Bearing, Single, Seal, 1630-RS 2
12 00008720 Bushing, 1/2 x 3/8 x 1/4, Bronze 1 47 00020282 Handle, Throw-Out 1
13 00008724 HHCS, 7/16-14, 1, Yellow Zinc 4 48 00020326 Throttle Cable 1
14 00008745 Screw, Round Head, Machine, 10-24 x 1/2 2 49 00020330 Belt Tensioner Rod, Zinc Plated 1
15 00008755 Clamp, To Hold Tubing on Handle 2 50 00020334 Jackshaft Complete 1
16 00008792 Woodruff Key, 3/16 x 3/4, #606 2 51 00020340 Reel Shaft 1
17 00009552 Small Pulley 1 52 01000377 Pin, Release Quick 3/8 Dia X3. 1
18 00009553 Large Pulley 1 53
19 00009557 V Belt 1 54 00051484 Plate Base 1
20 00009599 Sprocket, 40BS-10 x 3/4" BOR 1 55 00051485 Carton Top Cap & Top Frame 1
21 00009625 Chain #40 W/Master Link 1 56 00060017 Flat Washer, .06, .776, 1.25, SS 2
22 00009650 Master Link, #40 1 57 00060078 Grease Fitting, 1/4-28 x 3/16 STR 2
23 00009678 Clevis Pin, 3/8 x 1 1/8, Zinc 1 58 00090006 Decal, “Made In America 1
24 00009708 Carrige Bolt, 5/16-18 x 1-1/2 4 59 01002139 Decal, “MTD PRO” 1
25 00009748 Shaft Color, .760" x Bore w/SS Plate 6 60 01002393 Housing Assembly 1
26 00009812 Flat Washer, 5/16, SAE, Yellow Zinc 3 61 01002395 Belt & Chain Guard Assembly 1
27 00009816 Engine, Briggs & Stratton, 5 HP 1 62 01002397 Front Support Assembly 1
28 00009838 Lynch Pin, 3/8 x 2-1/4, Zinc 1 63 01002399 Reel Assembly 1
29 00009920 Lock Washer, 7/16, Zinc 4 64 01002401 Jackshaft Bearing Mount Assembly 1
30 00009968 Yoke, 3/8-24 Forged 1 65 01002403 Right Rear Wheel Axle 1
31 00010985 Cap, Screw, Socket Set, 5/16-18 x 1/4 1 66 01002405 Belt Tensioner 1
32 00011437 HHCS, Standard, 3/8-16 x 3/4, Zinc 2 67 00020342 Spacer, Belt Tensioner 1
33 00011971 Decal, “Grease Daily” 1 68 01002411 Handle Assembly w/Brace 1
34 00012156 Hex Nut, 3/8-24, Yellow 1 69 01002413 Handle Strut 1
35 00012157 Lock Washer, 3/8 Zinc 69
