Information
Main Specifications
Storage Precautions
• Clean the lens after use. Remove dust and dirt on the surface of the lens with a blower
brush or brush. Use commercially available lens cleaning paper to remove the dirt on the
lens. Do not use organic solvents.
• Always cap the lens and store it when it is not used.
• Do not store in an area with insect repellent.
x Notes on Shooting
• Edges of pictures may be cut off if more than one filter is used or if a thick filter is used.
Items 14-42 mm 17 mm
Mount Micro Four Thirds mount
Focal length 14-42 mm 17 mm
Max. aperture f3.5 - 5.6 f2.8
Image angle 75.4°-28.9° 64.9°
Lens configuration
8 groups, 9 lenses 4 groups, 6 lenses
Multilayer film coating
Iris control f3.5 - 22 f2.8 - 22
Shooting range 0.25 m - ) 0.2 m - )
Focus adjustment AF/MF switching
Weight (excluding hood
and cap)
150 g 71 g
Dimensions
(Max. diameter × overall
length)
l62 × 43.5 mm l57 × 22 mm
Filter mount thread
diameter
40.5 mm 37 mm
