Appendix JV500/V520 Bar Code Reader Protocol
308
System Setting
Shown below are the system settings of the V500-C11 and V520-R121 when this protocol is used.
Note The portions enclosed by in boxes are used for this protocol.
V500-C11
BCR Functions
Read trigger
READ SIGNAL INPUT, ONLINE READ COMMAND
Read control method
SINGLE READ, CONTINUOUS READ
Host Interface
Prefix
NONE, STX
Suffix
ETX , CR
Bar code output
OUTPUT , NO OUTPUT
V520-R121
Start code
NONE, STX
Stop code
ETX , CR
Operation mode
External trigger, host trigger
Data output mode
1-shot, continuous
