Safety Information and Introduction
En-11
Remote Controller
To control the AV receiver, press RECEIVER to
select Receiver mode.
For detailed information, see the pages in
parentheses.
RECEIVER button (21)
REMOTE MODE/INPUT SELECTOR buttons
(29)
// / and ENTER buttons
Q SETUP button (52)
Listening Mode buttons (41)
DIMMER button (49)
DISPLAY button (49)
MUTING button (50)
VOL / button (29)
RETURN button
HOME button (51)
SLEEP button (49)
Tip
• You can also use the remote controller to control Onkyo
Blu-ray Disc/DVD player, CD player, and other
components.
See “Entering Remote Control Codes” for more details
(➔ page 76).
■ Controlling the tuner
To control the AV receiver’s tuner, press TUNER (or
RECEIVER).
You can select AM or FM by pressing TUNER
repeatedly.
/ buttons ( 38)
D.TUN button (38)
DISPLAY button
CH +/– button (39)
Number buttons (38)
*1
These buttons can also be used when a REMOTE
MODE other than Receiver mode is selected.
■ Aiming the remote controller
To use the remote controller, point it at the AV
receiver’s remote control sensor, as shown below.
■ Installing the batteries
Note
• If the remote controller doesn’t work reliably, try replacing
the batteries.
• Don’t mix new and old batteries or different types of
batteries.
• If you intend not to use the remote controller for a long time,
remove the batteries to prevent damage from leakage or
corrosion.
• Remove expired batteries as soon as possible to prevent
damage from leakage or corrosion.
Controlling the AV Receiver
*1
*1
*1
*1
RECEIVER
Remote control sensor
AV receiver
Approx. 16 ft. (5 m)
Batteries (AA/R6)
