User Manual BDS4622V/R and BDS4624R
50
RGB/DVI for VESA Standard
This monitor supports many kind of input signals.
These Factory default signals (RGB mode) are shown in the table below:
Notes:
● If the signal source is out of range of the monitor,
the message "Signal Out of Range" will be displayed on the screen.
● You can confirm the format of signals from the Information Menu
under the OSD menu
N0 Dot x Line Horizontal
Frequency
(KHz)
Vertical
Frequency
(KHz)
Dot Clock
Frequency
(MHz)
Remark
1 720 x 400 31.47 70.08 28.32 DOS
2 640 x 400 37.90 85.00 31.50 VESA
3 640 x 480 31.50 60.00 25.18 DOS
4 640 x 480 35.00 67.00 30.24 Mac.(SOG)
5 640 x 480 37.50 75.00 31.50 VESA
6 640 x 480 37.86 72.81 31.50 VESA
7 640 x 480 43.30 85.00 36.00 VESA
8 800 x 600 35.16 56.25 36.00 VESA
9 800 x 600 37.90 60.32 40.00 VESA
10 800 x 600 46.90 75.000 49.50 VESA
11 800 x 600 48.08 72.19 50.00 VESA
12 800 x 600 53.70 85.00 56.25 VESA
13 832 x 624 49.00 74.00 57.27 Mac.(H+V)
14 1024 x 768 48.40 60.00 65.00 VESA
15 1024 x 768 56.50 70.00 75.00 VESA
16 1024 x 768 60.00 75.00 78.75 VESA
17 1024 x 768 68.70 85.00 94.50 VESA
18 1280 x 1024 64.00 60.00 108.00 VESA
