22
Tip
The router may fail to assign an IP address,
Protocol) is unavailable or disabled on the
router. You may need to enter the IP address
manually, or press BACK to start re-
connecting.
Connect to the Internet
Connect to the Internet as prompted.
»
time setup is complete.
Note
Ensure that the router connects to the
Internet directly and no dial-up is required on
the computer.
2/2
Wireless (W
i
F
i
)
Wired (Ethernet)
NP3700
Internet
To enter the desired digits, use the
alphanumeric buttons on the remote
control; or press
/ repeatedly.
Note
Ensure that you never enter an IP address that
is already assigned to a computer/device on
the network.
Wired connection
Connect to the router by using the Ethernet
cable
1 Select [Yes], when asked whether to set
up network connection (see ‘First-time
setup’).
2 Use an Ethernet cable to connect the unit
to the router.
Connect to the home Wi-Fi/wired network
On the unit, select [Wired (Ethernet)].
» The unit starts to acquire an IP address
assigned by the network automatically.
» A message appears when the
connection is completed successfully.
NP3700
p
DC IN ETHERNET
DOCKING
MP3 LINK
LAN4To Modem12V=1A ResetLAN3 LAN2 LAN1
EN
