48-Port 10/100/1000Mbps with 4 Shared SFP Managed Security Switch
Product
Specification
Model
Hardware Specification
Copper Ports
SFP / mini-GBIC Slots
Switch Architecture
Switch Fabric
Switch Throughput
Address Table
Share Data Buffer
Flow Control
Jumbo Frame
LED
Layer 2 Function
Management Interface
Port Configuration
Port Status
VLAN
Link Aggregation
QoS
IGMP Snooping
Access Control List
SNMP MIBs
Standards Conformance
Regulation Compliance
Standards Compliance
Physical Specifications
Dimensions (W x H x D)
Weight
Environment Specifications
Operating
Storage
WGSW-48040
48 10/100/1000Base-T RJ-45 Auto-MDI / MDI-X ports
4 SFP interfaces, shared with Port-23, Port-24, Port-47 and Port-48
Store-and-Forward
96Gbps / non-blocking
71.4Mpps
8K entries
12 Mbits
Back pressure for Half-Duplex
IEEE 802.3x Pause Frame for Full-Duplex
9K bytes
Power, Link / Act per port
Console, Telnet, SSH, Web Browser, SSL, SNMPv1, v2c and v3
Port disable / enable. Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable / enable. Bandwidth control on each port
Display each port's speed duplex mode, link status, and Flow control status. Auto negotiation
status, trunk status
802.1Q Tagged Based VLAN, up to 255 VLAN groups
Supports 8 groups of 8-Port trunk, IEEE 802.3ad LACP
Traffic classification based on Port Number, 802.1p priority, DSCP / TOS field in IP Packet
IGMP (v1 / v2) Snooping, up to 32 multicast Groups
IP-Based ACL / MAC-Based ACL, Up to 256 entries
RFC-1213 MIB-II
RFC-2863 Interface MIB
RFC-2665 EtherLike MIB
RFC-1493 Bridge MIB
RFC-2674 Extended Bridge MIB
RFC-2819 RMON MIB (Group 1, 2, 3 and 9)
RFC-2737 Entity MIB
RFC-2618 RADIUS Client MIB
FCC Part 15 Class A, CE
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3z Gigabit SX / LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1d Spanning tree protocol
IEEE 802.1w Rapid spanning tree protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1s Multiple Spanning Tree protocol
430 x 350 x 44.5 mm, 1U height
3.5 KG
Temperature 0°C ~ 50 Degree C
Relative Humidity 20% ~ 85% (non-condensing)
Temperature -40°C ~ 70 Degree C
Relative Humidity 20% ~ 90% (non-condensing)
Data Sheet
3
WGSW-48040
