18
TRACTOR - MODEL NO. PB175A42LT (96048003700), PRODUCT NO. 960 48 00-37
DECALS
KEY PART
NO. NO. DESCRIPTION
1 532 43 90-60 Decal, Fender RH/LH Set
2 532 44 66-06 Decal, Replacement
3 532 43 10-92 Decal, Engine HP
4 532 17 05-63 Decal, Warning
5 532 43 52-86 Decal, Dash Lower
6 532 41 16-58 Decal, Fender Warning (E&F)
7 532 43 85-01 Decal, Ins Str Wh
8 532 44 83-80 Dceal, SDPNL
9 532 44 52-34 Decal, Fender
10 532 16 03-96 Decal, V-Belt Sch.
12 532 44 52-35 Decal, Hood RH/LH
15 532 14 50-05 Decal, Caution, Battery
- - 532 16 69-60 Decal, Bypass
- - 532 40 95-05 Pad Footrest LH
- - 532 41 12-73 Pad Footrest RH
- - 532 44 83-76 Manual, Operator's, (English /French)
- - 532 44 83-77 Manual, Parts,(English /French)
KEY PART
NO. NO. DESCRIPTION
1 532 05 91-92 Cap, Tire Valve
2 532 06 51-39 Stem, Valve
3 532 10 62-22 Tire, Front
4 532 05 99-04 Tube, Front (Service item only)
5 532 43 96-73 Rim Assembly, 6" Front
6 532 12 49-57 Fitting, Grease (Front wheel only)
7 532 12 49-59 Bearing, Flange (Front wheel
only)
8 532 44 08-81 Rim Assembly, 8" Rear
9 532 42 05-31 Tire, Rear
10 532 12 49-26 Tube, Rear (Service item only)
11 532 17 50-39 Cap, Hub Axle
- - 532 14 43-34 Sealant, Tire (10 oz. Tube)
6
2
1
5,8
4,10
3,9
11
7
wheel_1
KEY PART
NO. NO. DESCRIPTION
WHEELS & TIRES
7
12
12
10
6
15
3
8
4
2
5
1
1
5
9
