Samsung SCH-i600 2003 OS Upgrade
Page 3 of 5 Release Date: 07/2004
1.2 IMPORTANT NOTIFICATIONS
After installing the above software, applications make certain:
1. You synchronize/back-up all of your personal data with your PC via ActiveSync.
2. You have a live internet connection. (Broadband/DSL/Hi-Speed connection is preferred)
3. Disable the stand-by and hibernation modes on your PC.
4. The SCH-i600 phone radio connection is turned on. To verify the radio is on, the antenna and signal
strength icon should appear as
.
5. Your SCH-i600 cradle is connected directly to your PC USB port and NOT through a USB Hub or any
other USB pass-through device.
6. Your SCH-i600 cradle is connected and plugged into a power outlet.
1.3 START UPGARDE PROCESS
1. Directly connect the Samsung SCH-i600 Desktop/Sync cradle to your PC and to a power outlet.
2. Download the Upgrade Tool file (Samsung_i600_UpgradeTool.zip) to your PC desktop.
3. Double-click the Upgrade Tool file and extract the folder to your PC desktop.
4. Double-click the i600 Upgrade Tool folder on your desktop.
5. Double-click the mobile device icon
to run the application.
6. CAREFULLY, follow the on-screen instructions to begin the upgrade process.
7. Once the upgrade of the operating system is complete, you must accept the changes made to the
operating system by performing the following steps:
1. Undock the device from the Desktop/Sync cradle
2. Remove the battery
3. Replace the battery and power-on the device
When the SCH-i600 handset powers up the home screen
should appear as the screen image to the right:
