Exploded and assembling View
This Document can not be used without Samsung's authorization
SAMSUNG Proprietary-Contents may change Without notice
8-4
SILK line agreement confirm certainly.
1) Be careful a damage of connector.
2) Press equally actuator.
3) Silk line agreement confirm certainly.
8 9
10
11
12
Arrange SPEAKER WIRE lest should be chewed and assemble SPEAKER
BRACKET .
2) Screw 2 points marked in red circle.
.
2)
Confirm whether become side by side with base line.
7
Screw 4 points marked in red circle.
After insert FPCB to FRONT's FPCB HOLE, Put the FRONT on slide.
2) After screw 6 points sequentially using a screwdrive, combine
3*4 KEY PAD with FRONT structure.
1) After remove white paper, Insert F-PCB to CONNECTOR.
2)
3) Press equally actuator.
Press CONNECTOR equally
Fold here once so
that FPCB may fold
easily.
Base line
that fold F
PCB
TAPE
sticking
base line
Press
equally
Actuator.
Comfirm
base line.
Remove white
paper
