How to Change Dust Bag
and Motor Filter
CAUTION: Turn off the switch and unplug the electrical cord
before servicing the cleaner. Never operate the vacuum
cleaner without the dust bag in place.
NOTE: When cleaning new carpet for the first time, bag will fill
quickly. Check often.
Change dust bag V when display F turns orange (can be checked with
the appliance operating at maximum suction and with the nozzle raised
from the floor). A change may be necessary even if the bag does not
appear to be full. Fine dust can block the pores and reduce the suction
power of the appliance.
• Remove hose and open the bag cover lid by pulling release catch G.
• Remove dust bag V by pulling on the sealing tab.
• Push new dust bag into the retainer until it clicks into place. Take care
when closing the dust chamber lid that the dust bag is completely
inside the dust chamber border. The dust chamber lid will not close
unless a dust bag has been inserted. Please do not use force!
• Change motor filter Z if display F is still orange after the dust bag
has been changed or if the suction power is significantly reduced
although the dust bag has little in it.
• Replace hose.
How to Clean Washable HEPA Filter
CAUTION: Turn off the switch and unplug the electrical cord
before servicing the cleaner. Never operate the
vacuum cleaner without the filter in place.
• Clean filter X if display C is lighted or if the suction power is
significantly reduced.
• Press filter cover button W and open filter cover Y.
• Cleaning the washable HEPA filter:
• Wash HEPA filter when indicator C is lighted.
• Open and remove the lid Y, then remove the filter X.
• Rinse the inside (dirty side) of the filter with warm tap water. Tap
the filter frame to remove excess water. Repeat four times and
allow to dry.
NOTE: Do not use cleaning agents and avoid touching the
delicate filter surfaces.
• Replace the filter and lid.
4
G
F
V
Z
W
Y
X
C
C
How to Replace Worn Belt or Light Bulb
CAUTION: Disconnect power cord and wands from electrical hose before replacing belt or bulb. Belt pulleys can become
hot during normal use. To prevent burns, avoid touching the belt pulley when servicing the drive belt.
2. Remove two screws located in front of the light
bulb and lift up to remove the brush roll cover.
1. Remove two screws from bottom side. To turn over, grasp hood near
handle socket and lift forward.
Replace headlight bulb, if necessary. Support socket with one hand
and push light bulb into socket; turn to release. Place new light bulb
into socket; turn to secure. Push light bulb and socket back so bulb
will not touch lens cover. Use GENUINE SANITAIRE replacement
bulb, 59224.
Continue to step 2 to change belt.
Skip to step 7 and 8 to replace hood
on motorized nozzle.
3. Lift out brush roll;
replace new belt
around brush roll
shaft.
