16
3. Hang the TV onto the arm assembly/wall plate
11
by hooking the top support.
4. Press the bottom of the TV into the arm assembly/wall plate
11
until the safety catch locks the TV in place.
5. Turn the safety release pin clockwise until the pin springs back into place and locks the release cord.
CAUTION: Avoid potential personal injury or property damage! Always make sure the safety release pin is fully seated and the release
cord is locked, so the TV is securely fastened to the arm assembly/wall plate
11
53
4
Top
Support
Safety
Catch
Safety
Release
Pin
11
