Cheetah 10K.7 36GB FC Product Manual, Rev. A 61
Figure 14. J6 connector dimensions
9.5.3 Electrical description
Fibre Channel drives use the FC-SCA connector for:
DC power
FC-AL interface
Drive select (device identification)
Option selection
Enclosure Services interface
This 40-pin connector is designed to plug directly into a backpanel. External cables are not required.
.787
(19.99 mm)
.079 (2 mm)
.079
(
2 mm)
.708
(17.983 mm)
J6
