7-7
CHAPTER7
20-BIN STAPLE SORTER (AR-SS2)
Using the optional RADF
1
Set the originals in the document feeder tray face up
with the stapling position in the upper left corner.
●
If the number of copies to be delivered into each bin is more than
30 for 8-1/2" x 11" or 8-1/2" x 11"R paper or 25 for 8-1/2" x 14"
or 11" x 17" paper, the copies will not be stapled.
2
Press the OUTPUT key and select the STAPLE SORT
mode.
●
Make sure that there is no paper in any sort bin before selecting
the STAPLE SORT mode.
3
Set the number of copies.
●
Up to 20 sets can be made.
4
Press the COLOR COPY START ( ) key or BLACK
COPY START ( ) key.
●
When copying and sorting are completed, each set of copies will
be automatically stapled.
●
Sets of copies containing copies of different width will not be
stapled.
OPTIONAL EQUIPMENT
20-bin staple sorter (AR-SS2)
Stapling position
SORT
STAPLE
SORT
GROUP
OK
PAPER SELECT
100%
COPY RATIO
8/ 11AUTO
1
2
12
3
456
789
0
P
C
CA
CLEAR
PROGRAM
AUDIT
INTERRUPT
CLEAR
ALL
N
3
6
9
P
C
CA
CLEAR
PROGRAM
INTERRUPT
CLEAR
ALL
