19
COPY FUNCTIONS
2
3
Set the original(s) face up in the
document feeder tray.
● The ORIGINAL SIZE indicator corresponding to the
size of the original lights up.
● Insert the original into the document feeder tray as
far as it will go. When the original is set, the
SPF/RSPF indicator will light up.
● Make sure that the ORIGINAL TO COPY indicators
are not lit. (When automatic two-sided copying is
supported.)
● Make sure that the PAPER SIZE indicator is lit.
● If the indicator is not lit, paper of the same size as
the original is not loaded in the trays. Change the
paper in a tray, or use the bypass tray.
● To copy on paper of a different size than the
original, select the paper with the [TRAY SELECT]
key.
● The bypass tray is not selected automatically.
Originals that can be used in the SPF/RSPF
Originals that are 11" x 17" to 5-1/2" x 8-1/2" and 15
lbs. to 24 lbs. (56 g/m
2
to 90 g/m
2
) can be used. A
maximum of 40 pages can be placed at once.
Auto paper selection
This function automatically selects the paper that is the
same size as the original (only 11" x 17, "8-1/2" x 14",
8-1/2" x 11"R, and 8-1/2" x 11" paper).
• If a zoom setting is selected after placing the
original, the paper size that is appropriate for the
zoom setting will be automatically selected.
• "Auto paper selection" is canceled if the auto zoom
select function is enabled (p.00) or if a tray is
selected with the [TRAY SELECT] key. Auto paper
select resumes operation when the [CLEAR ALL]
key ( ) is pressed or when "Auto clear" activates.
"Auto paper selection" can be disabled in the user
programs. (p.00)
Originals that cannot be used in the
SPF/RSPF
The following originals cannot be used. These may
cause misfeeds or smudging and unclear images.
• Transparencies, tracing paper, other transparent or
translucent paper, and photographs.
• Carbon paper, thermal paper.
• Originals that are creased, folded, or torn.
• Glued originals, cut-out originals.
• Originals with binder holes.
• Originals printed using an ink ribbon (thermal
transfer printing), originals on thermal transfer paper.
Stream feeding mode
If "Stream feeding mode" is enabled in the user
programs (p.00), the SPF/RSPF indicator will blink for
about 5 seconds after all originals are fed. If a new
original is placed in the SPF/RSPF during this time, the
original will automatically feed in and copying will
begin.
4
Select copy settings.
See the following pages to select the copy settings that
you wish to use.
● Select the resolution and exposure:
"MAKING A COPY DARKER OR LIGHTER". (p.00)
● Change trays:
"SELECTING THE TRAY". (p.00)
● Set the number of copies:
"SETTING THE NUMBER OF COPIES". (p.00)
● Enlarge or reduce a copy:
"REDUCTION/ENLARGMENT/ZOOM". (p.00)
● Perform automatic two-sided copying on a model
that supports this feature:
"AUTOMATIC TWO-SIDED COPYING". (p.00)
● When the Dual function board is installed, copy
using sort/group, 2 IN 1 / 4 IN 1, margin shift, or
erase functions:
"CONVENIENT COPY FUNCTIONS". (p.00)
5
Press the [START] key ( ) and start
copying.
The copy is delivered to
the output tray. The
output tray can hold up to
250 sheets of paper.
About one minute after
copying ends, "Auto
clear" activates and
restores the copy
settings to the initial
settings. (p.00)
Do not place originals of different sizes
together in the document feeder tray. This
may cause misfeeds.
• Make sure that there are no paper clips or
staples on the original.
• Straighten curled originals before placing
them in the document feeder tray. Curled
originals may cause misfeeds.
• When using the margin shift function, check
the position of the margins carefully. (p.00)
Note
Note
Press the [CLEAR] key ( ) to stop copying
in the middle of a run.
Note
