The DFWA-400 host adapter card is an IEEE1394 serial bus interface card. You can install this card in the PCI bus slot in IBM
PC/AT compatible computer.
Features
PCI interface
Complies with PCI Short Card (5 V, 32-bit) standard
Complies with PCI Local Bus Rev 2.1 standard
Supports the PCI Bus Master function
Supports the PCI Bus DMA transfer function
IEEE1394 interface
High-speed data transfer rate: 100M/200M/400M bits/second
Supports both asynchronous transfer and isochronous transfer
Supports the isochronous cycle master function
Provides three 6-pin connectors to connect the camera module
Recommended Specifications for Personal Computer (PC)
Processor : Pentium 500 MHz or more
Free main memory : 40 MB or more
Video memory : 8 MB or more
Display mode : Can display 1,280 × 1,024 (true color)
Expansion slot : With 1 × PCI bus
OS : Windows* 98 or Windows* NT4.0
NOTE
: For details on the peripherals and the computer to which you are connecting the DFWA-400
card, see the respective manuals.
* “Windows” is a trademark of Microsoft Corporation, registered in the U.S.A. and other countries.
Note) Zenkuman (indicated on the card) is a registered trademark of Technoscope, Co., Ltd.
HOST ADAPTER CARD DFWA-400
