PAGE 2 menu
This section describes in detail items on PAGE 2 menu.
The following table shows the PAGE 2 menu items, their
contents and reference pages in this manual.
C. TEMP
Selects the color temperature according to the lighting.
Selection Lighting condition
AUTO
Use for automatic adjustment of the color
temperature with “WHIT.BAL” set to “AWB”.
Use for indoor shooting.
Use for outdoor shooting.
3200K
5600K
WHIT.BAL
Selects the white balance settings.
Selection Function
AWB
Use for automatic adjustment of the white balance.
For details, see “Adjusting the White Balance.”
For details of how to make fine adjustment using “R Paint”
and “B Paint”, see the following ATW.
MANU Use for manual adjustment of white balance. Both red
gain (R gain) and blue gain (B gain) are adjustable.
R Gain: Adjusts the red gain (-127 to +127)
B gain: Adjusts the blue gain (-127 to +127)
Ptress the DATA UP and DATA DOWN buttons
together, to reset the values to ±000.
(Continued)
a) This item appears when DETAIL is set to ON.
>
:A
±
00
±
00
ON
ON
PAGE 2 : NOR
M. PEDESTAL
GAMMA
DETA L
scan
AUTO
AWB
C. TEMP
W
HT. BAL
I
R P
B P
a nti
a nti
±
00
LEVEL
±
00
Item Contents of setting Ref. page
C.TEMP Selects the color temperature
according to the lighting condition.
WHIT.BAL Selects the white balance settings.
M.PEDESTAL Sets the pedestal level of the output
signal.
GAMMA Gamma compensation (on/off).
DETAIL Enables and disables the DETAIL
function (on/off).
LEVEL
a)
Adjusts the sharpness of the object
outline.
19
19
20
20
20
21
