Connecting to a VCR or stereo system
Example C
How to connect to a stereo system
Connect the t LIGNE-2 G o D jacks on this VCR to the audio output
jacks on the stereo system, using the RK-C510HG audio cable (not
supplied).
Notes
• Make sure you connect the plugs to jacks of the same colour.
• If the other VCR is a monaural type, leave the red plugs unconnected.
• If you connect this VCR to both the ENTREE LIGNE and SORTIE LIGNE jacks
of the other VCR, select the input correctly to prevent a humming noise.
• If the other VCR does not have a PERITEL connector, use the VMC-2106HG
cable instead and connect the cable to the line out jacks of the other VCR.
• When you connect another VCR to the DECODEUR/ENTREE LIGNE-3
connector, set DECODEUR/LIGNE3 to LIGNE3 in the OPTIONS-2 menu.
TV
DECODEUR/
t ENTREE
LIGNE-3
VMC-2121HG PERITEL cable (not supplied)
PERITEL
: Signal flow
Your VCR (Recorder)
Other VCR (Player)
