4CH/8CH MPEG4 Multiplex Network DVR
Features
‧ MPEG4 compression for DVR recording and web transmission
‧ Graphic OSD and mouse control
‧ Live display, record, backup, playback and network access at
the same time
‧ CD / DVD writer (selectable) and USB device backup
‧ Remote view and manage through 16CH client software and
IE browser
‧ Audio recording
‧ Motion detection with area selecting and sensitivity adjusting
by each camera
‧ Remote controller
‧ Email noti cation
‧ Control all functions of PTZ camera
‧ TCP/IP, DDNS, DHCP, PPPoE network connection
‧ System auto recovery after power reconnected
‧ Watermark proof
‧ Motion / manual / continuous / alarm recording
‧ Multi-language OSD
Model No. RYK-9334 RYK-9338 RYK-9348
Video
Format NTSC / EIA or PAL / CCIR
Compression MPEG4
Input 4 CH, BNC 8 CH, BNC
Loop Output
－
Option
Main Output 1 CH, BNC
VGA Option
Spot Output 1 CH, RCA
Audio
Input 4 CH, RCA
Output 1 CH, RCA
Display
Resolution 720x480 (NTSC), 720x576 (PAL)
Frame Rate Max. 120 / 100 IPS (NTSC / PAL) Max. 240 / 200 IPS (NTSC / PAL)
Division Single, Quad, Sequence Single, Split (4,9), Sequence
Recording
Resolution 704x480, 704x240, 352x240 (NTSC), 704x576, 704x288, 352x288 (PAL)
Frame Rate 120 IPS@CIF 120 IPS@CIF 240 IPS@CIF
Quality Highest, Medium, Low
Pre Alarm Max. 120 frames
Post Alarm 5 ~240 seconds
Mode Manual / Schedule / Event (Motion Detection / Video loss / Sensor)
WaterMark Yes
Storage
HDD 2x3.5” IDE HDD (Max. 750GB)
Option SATA converter
Requirement 5400 ~ 7200RPM, 45MHz DMA, EIDE compatible, Faster than 9.0ms avg.
Alarm
Input 4 (NO / NC programmable) 8 (NO / NC programmable)
Output 1 Relay with NO / NC contact
Triggered Mode Motion Detection, Video Loss, Sensor Input, Power Failure
Action Recording, Relay Output, Sound Alert
Network
Protocol TCP/IP, SMTP, HTTP, DHCP, PPPoE, DDNS
Remote View, Search, Recording & Control by Client Program or IE Browser
Backup Device USB (Flash Memory, USB HDD), CD / DVD writer (option)
PTZ Camera Support
Backup File Format MPEG4 compression, AVI le format
Multi-Language English, Traditional Chinese, German, French, Italian, Spanish
Search Method By Date, Time, Event
Serial Connectors USBx3, RS-232C, RS-485
Power Supply AC100~240V 50/60 Hz, DC12V
Weight Approx. 3.6 Kg (without HDD)
Dimensions (WxHxD) 430x70x310 mm
Operating Environment 30 ~ 80% RH, 5°C ~ 40°C (41°F ~ 104°F)
■
IPS: Images Per Second
