14
XC-E series
OUTPUT WAVEFORM TIMING CHART
(XC-ES50/EI50/ES30/EI30(EIA))
Timing chart of horizontal output waveform
Timing chart of vertical output waveform (2:1 interlaced frame integration)
91 (6.36
µ
s)
69.8 ns
40 77 22 3 15 752
Effective total pixel 768
Horizontal blanking period (11.0
µ
s)
One horizontal scanning period (1 H)
910
(
63.56
µ
s
)
Output video period
752 (52.5
µ
s)67 (4.68
µ
s)
HSYNC
70
(4.89 µs)
21
(1.47 µs)
HD
Camera video
output signal
(Typical value)
CCD
output
signal
Optical black portion
Horizontal transfer stop period
Dummy
pixel
Optical black
portion
Odd field (262.5 H)
253.5 H 253.5 H
489
494
491
490
492
494
9 H
Vertical blanking
period (20 H)
Vertical blanking
period (20 H)
9 H
Even field (262.5 H)
VD
Camera
video
output
signal
CCD
output
signal
1 3 5 7 9 2 4 6 8
681 4 242.5 3.5 242.5
682
493
Optical black portion
Empty
transfer
Optical black portion
Empty
transfer
