28
XR-CA600/CA600V/CA600X
*1 Loading motor control
STOP
LOADING/
FORWARD
EJECT/
REVERSE
BRAKE
LMLOD (pin il )
“L”“H”“L”“H”
LMEJ (pin o; )
“L”“L”“H”“H”
Terminal
Mode
Pin No. Pin Name I/O Description
83
ILLON O
Power on/off control signal output of the illumination LED and liquid crystal display driver
(IC900) “H”: power on
84 REL I
Rotation detection signal input from supply reel sensor and take-up reel sensor on the mechanism
deck
85 POS3 I
86 POS2 I
87 POS0 I
88 POS1 I
89 LMLOD O
Motor drive signal output to the loading motor drive (IC351) “H” active
(For the loading direction and forward side operation) *1
90 LMEJ O
Motor drive signal output to the loading motor drive (IC351) “H” active
(For the eject direction and reverse side operation) *1
91 TAPEON O
Power on/off control signal output of the loading motor drive (IC351) and capstan/reel motor
(M901) “H”: motor on
92 CMON O
Capstan/reel motor (M901) drive signal output terminal “H”: motor on
93 NOSESW I
Front panel block remove/attach detection signal input from the nose detection switch (S552)
“L”: front panel is attached, “H”: front panel is removed
94 NS_MASK O
Discharge control signal output for the noise detection circuit “H”: discharge
95 DAVSS —
Ground terminal (for D/A converter)
96 to 99
NCO O Not used (open)
100 DAVCC —
Power supply terminal (+5V) (for D/A converter)
Tape position (EJECT/FF/REW/REV/
FWD mode) detect input from the tape
operation switch on the deck mechanism
POS3: “L”: REV and EJECT mode, “H”: others mode
POS2: “L”: REW mode, “H”: others mode
POS0: “L”: EJECT mode, “H”: others mode
POS1: “L”: PLAY and FF in FWD mode, and REW
in REV mode, “H”: others mode
