Teledyne API – Model T700 Dynamic Dilution Calibrator Overview of Operating Modes and Basic Operation
149
NO. VARIABLE DESCRIPTION
ALLOWED
VALUES
DEFAULT
VALUES
3
O3_PHOTO_BENCH_ONLY
2
O
3
bench control flag.
ON turns on the photometer pump and
switches measure/reference valve only
when the O
3
mode is set for BNCH (See
Section 3.4.8).
ON/OFF OFF
4
STD_TEMP
1
Sets the standard Temperature used in
calculating O
3
flow rates and concentrations.
0ºC and 100ºC 25ºC
5
STD PRESSURE
1
Sets the standard pressure used in
calculating O
3
flow rates and concentrations.
15.00 – 50 .00
in-Hg-A
29.92 in-Hg-A
6
CLOCK_ADJ
Adjusts the speed of the analyzer’s clock.
Choose the + sign if the clock is too slow,
choose the - sign if the clock is too fast (See
Section 4.5).
-60 to +60 s/da
y
Default=0
0
1
DO NOT ADJUST OR CHANGE these values unless instructed to by Teledyne API’s customer service personnel.
2
Only available in calibrators with O
3
photometer and generator options installed.
IMPORTANT
IMPACT ON READINGS OR DATA
There is a 2-second latency period between when a VARS value is
changed and the new value is stored into the analyzer’s memory. DO NOT
turn the analyzer off during this period or the new setting will be lost.
