TC14/TC18
EUROPE
COMPONENTS
ITEM QTY . P/N DESCRIPTION ITEM QTY . P/N DESCRIPTION
1 1 33424 TC14 230V EUROPEAN TOASTER TOP HEATER
ASSY(240V/1060W)
2 1 33425 TC14 230V EUROPEAN TOASTER BOTTOM HEATER
ASSY (240V/1060W+250W)
3 16 2001371 NUT, KEPS 10-32
4 1 33397 SHAFT ASSEMBLY, REAR (with sprockets)
5 1 33396 SHAFT ASSEMBLY, FRONT (with smooth rollers)
6 2 7610849 KIT, FRONT BEARING ASSEMBLY (inc. items 7-8)
7 1 7008178 BEARING, FRONT
8 1 3103262 SPRING
9 1 3102930 RETAINER, E-RING, 5/16/7.9mm
10 1 7006964 BEARING, REAR RIGHT
11 1 7006963 BEARING, REAR LEFT
12 1 34129 SPROCKET, DRIVE SHAFT, 12T
14 1 7007605 DRIVE CHAIN (15"/381mm)
15 1 3101212 MASTER LINK, DRIVE CHAIN
16 1 33392 BELT, CONV (10 x 25/254x635mm, 85 links)
17 3 33394 MASTER LINK, CONVEYOR BELT
18 1 42681 BOTTOM PANEL
19 4 3B20A8801 SCREW, HWH 8-32 x 3/8
20 1 27470-0004 FAN GRILLE
21 4 21226-0007 SCREW, SLT PNHD 10-24 x 1/2
22 1 33406 TERMINAL BLOCK, 3-POLE
23 1 27392-0002 COOLING FAN, 115V
24 1 31141 SPEED CONTROLLER FOR DC MOTOR
25 1 33388 SWITCH, PRODUCT SELECTION, 3-POSITION
26 1 30697 TRANSFORMER, 230Vp:115Vs
27 1 39344 LABEL, CONTROL PANEL
28 2 33402 KNOB
29 1 36439 CORD & PLUG (Kabelmetal-type HO7RN-F cord with
3x1,5mm conductors and moulded-on 250V, 16A plug)
30 1 33412 STRAIN RELIEF, BLACK PLASTIC
-- 1 31615 MOTOR & FUSE ASSEMBLY (inc. items 31-35)
31 1 3002757 MOTOR, CONVEYOR DRIVE, 115VDC
32 1 30155 KIT, MTR BRUSH & CAP (inc. items 33-34)
33 2 30154 CAP, PLASTIC
34 2 30153 MOTOR BRUSH
35 1 31053 FUSE, 0.25A 125V
36 4 2000177 SCREW, SLT HEX WSHR HD #10-32 X 1/4
37 1 34128 SPROCKET, MOTOR, 20T (with set screw)
NOT SHOWN:
-- 1 34897 RFI FILTER
-- 3 36437 FUSE, 1.0A 250V
-- 1 33387 BOTTOM COMPARTMENT INSULATION, FOIL-BACKED
-- 4 3101254 INSULATION CLIPS
-- 1 34082 WIRESET
-- 1 30930 CORDSET, COOLING FAN
