Pin Assignment
Satellite U400/Satellite Pro U400/PORTEGE M800 Maintenance Manual 13
P/N:DFWF03MS000 CONN SMD WAFER,3P,1R,MS(P1.25,H4.7)
PIN No. Signal name I/O PIN No. Signal name I/O
1 TH_FAN_POWER --- 2 GND ---
3 +3V/ FANSIG ---
CN23 HDMI connector
P/N:DFHD19MR011 CONN SMD HDMI 19P 2R MR(P1.0,H6.53)
PIN No. Signal name I/O PIN No. Signal name I/O
1 HDMITX2P O 2 GND ---
3 HDMITX2N O 4 HDMITX1P O
5 GND --- 6 HDMITX1N O
7 HDMITX0P O 8 GND ---
9 HDMITX0N O 10 HDMICLK+ I/O
11 GND --- 12 HDMICLK- I/O
13 CEC --- 14 NC ---
15 HDMI_DDCCLK I/O 16 HDMI_DDCDATA I/O
17 GND --- 18 DDC5V ---
19 HDMI_HP --- 20 GND ---
21 GND --- 22 GND ---
23 GND ---
CN24 DDR2 SO-DIMM(200P) slot
