Chapter 1. Product Overview
With the excellent circuit design and high quality production, we guarantee the ADSL2+ Router’s
high performance, great stability and easy to use.
In addition to the basic DMT physical layer functions, the ADSL2+ PHY supports dual latency
ADSL2+ framing (fast and interleaved) and the I.432 ATM Physical Layer.
The TD-8841 is a complete plug-and-play solution. With standard Ethernet interface, it can be
directly connected to any 10M/100M Ethernet devices, support Auto-MDIX.
The TD-8841 not only uses html (web mode through Ethernet port) to configure the Router but
also uses external utility software. You can download it from our website (http://www.tp-link.com
).
1.1 Product Main Specification
¾ High speed and asymmetrical data transmit mode, provides safe and exclusive bandwidth
¾ Supports All ADSL2+ industrial standards
¾ Compatible with all mainstream DSLAM (CO)
¾ Firmware upgradeable
¾ Provides integrated access of internet and route function which face to SOHO user
¾ Advanced DMT modulation and demodulation
¾ Real-time Configuration and device monitoring
¾ Quick response semi-conductive surge protection circuit, provides reliable ESD and
surge-protect function
1.2 Supporting Protocol
¾ G.992.1 (G.dmt) - Annex A/B/C
¾ G.992.2 (G.lite) - Annex A/B/C
¾ ANSI T1.413
¾ G.992.3 (ADSL2) Annex A/B/C/M and Annex L (RE-DSL) compliant
¾ G.992.5 (ADSL2+) Annex A/B/C and Annex L (RE-DSL) compliant
¾ ADSL dual latency (fast path and interleaved path)
¾ I.432 ATM physical layer compliant
¾ Supports RFC2364 (PPPoA)
¾ Supports RFC2516 (PPPoE)
