300Mbps Wireless N Gigabit ADSL2+ Modem Router User Guide
4. Choose the wireless network from the drop-down list.
5. Click the Save button to save this entry.
To edit or delete an existing entry:
1. Click the Edit in the entry you want to modify.
2. Modify the information.
3. Click the Save button.
Click the Enable/ Disabled Selected button to make selected entries enabled or disabled.
Click the Delete Selected button to selected entries.
For example: If you desire that the wireless station A with MAC address 00:1D:0F:11:22:33 and the
wireless station B with MAC address 00:0A:EB:00:07:5F are able to access TP-LINK_997001
network, but all the other wireless stations cannot access this wireless network, you can configure
the Wireless MAC Address Filtering list by following these steps:
1. Click the Enable button to enable this function.
2. Select the radio button “Allow the stations specified by any enabled entries in the list to
access” for Filtering Rules.
3. Delete all or disable all entries if there are any entries already.
4. Click the Add New
button.
1) Enter the MAC address
00:1D:0F:11:22:33
/
00:0A:EB:00:07:5F
in the MAC Address field.
2) Enter wireless station A/B in the Description field.
3) Select Enabled from the drop-down list.
4) Choose the Host from the drop-down list.
5) Click the Save button.
6) Click the Back button.
The filtering rules that configured should be similar to the following list:
4.8.6 Wireless Advanced
Choose menu “Wireless””Wireless Advanced”, you can configure the advanced settings of
your wireless network.
49
