TL-WR641G 108M Wireless Router User Guide
- 56 -
Maximum Bandwidth Limit.
¾ Bandwidth – Specifies the bandwidth you want to supply to this entry.
¾ Description – Description of this entry.
¾ Enable – Enable this entry. This entry won’t be effective unless you check the
Enable box.
Click the Delete button to delete single entry.
Click the Delete All button to delete all entries.
Click the Save button to save all configuration.
For example, we assume that PC A, B, C are sharing the Internet with 2Mbps bandwidth
through one router. PC A is often for VoIP or online games, to guarantee its better performance
without interference from PC B and C, you can specify the minimum bandwidth for PC A such
as 100Kbps.
)
Note:
1. The conversion relation of bandwidth: 1 Mbps = 1000Kbps.
2. Please choose the Network Connection Type and set the bandwidth according to your
Network. If you are not clear about that, please contact with your ISP for help.
3. IP address range for different entries could not have intersection with each other.
4. After the configuration, click the Save button for the change to take effect.
4.11 IP & MAC Binding Setting
Figure 4-51
There are two submenus under the IP &MAC Binding menu (shown in Figure 4-51): Binding
Setting and ARP
List. Click any of them, and you will be able to scan or configure the
corresponding function. The detailed explanations for each submenu are provided below.
4.11.1 Binding Setting
This page displays the IP & MAC Binding Setting table; you can operate it in accord with your
