Setting Up A RADIUS Server 655
Configuring auto VLAN and QoS for Funk RADIUS
To set up auto VLAN and QoS using Funk RADIUS, follow these steps:
1 Edit the
dictionary file radius.dct so that Return list attributes from the Funk
RADIUS server are returned to the Switch 5500. The changes to make are:
a Add an R at the end of the correct attributes in the file, see example below.
The attributes will now appear as potential Return list attributes for every user.
2 After saving the edited
radius.dct file, stop and restart the Funk RADIUS service.
3 To use these return list attributes, they need to be assigned to a user or group.
Create a new user and add the return list attributes shown in Table 688.and
Table 689
Table 688 Summary of auto VLAN attributes
Table 689 Summary of QoS attributes
For Auto VLAN Return String Comment
Tunnel-Medium-type 802
Tunnel-Private-Group-ID 2 VLAN value
Tunnel-Type VLAN
For Auto QoS Return String Comment
Filter-id profile=student QoS Profile name
