ASUS P5W DH Deluxe 2-41
Use of a PSU with a higher power output is recommended when conguring a
system with more power consuming devices. The system may become unstable
or may not boot up if the power is inadequate. Refer to the Power wattage
tables below and on the next page for details.
Vendor Model Max. Power (W)
FSP 400-60THN 400
Seasonic SS-600HT 600
Seasonic SS-400FT 400
Acbel ATX-550CA-AB8FM 550
THERMALTAKE HPC-420-302 DF 400
AUSU S-30EP 300
Bestec ATX0400D5W 400
Silverstone SST ST56ZF 560
Enermax Eg701AX-VE 600
Power Supply Unit reference vendors list
Loading Heavy Normal Light
CPU Extreme Edition 965 Prescott 672 Conroe E6700
DDR2 800 1G*4 1G*2 512M*2
VGA ATI 1900XTX*2 NVIDIA 6800GTX*1 NVIDIA 6600*1
HDD IDE*2 IDE*1 IDE*1
SATA*5 SATA*3 SATA*2
CD-ROM 2 2 1
USB 7 6 4
PCI-E 1 1 1
PCI 2 2 1
Wi-Fi AP Solo™ Enabled Enabled Enabled
DH Remote Enabled Enabled Enabled
Required +12V
current
+12V-V2 +12V-V1 +12V-V2 +12V-V1 +12V-V2 +12V-V1
>12A >18A >12A >8A >12A >6A
Required wattage >=525W >=300W >=160W
Power wattage
