WIRELESS
GOOSENECKS
Condenser Gooseneck Microphone
GCU250
Slim and unobtrusive in design, this high-performance gooseneck provides smooth,
noiseless, and precise microphone positioning. It exudes a speech-tailored frequency
response with rich treble and bass. Minimal ambient and handling noise with high
intelligibility to cut through noisy backgrounds and large gatherings. Reliable and effi-
cient for clean, accurate vocal reproduction. Features integral windscreen, and an XLR
connector located under mounting base. (18-1/4" H x 3/4" dia., 4 ounces.)
• 15-1/4" adjustable neck
• Heavy all-metal case with non-glare black finish
• Ultra-compact, rugged design
• Cardioid pickup pattern
• Electret condenser element
• Phantom power operated (9-52V DC)
• 250-ohm impedance
• Wide frequency response range of 50 Hz - 18 kHz
• Sensitivity of -65 dB +/- 3 dB
Dynamic Gooseneck Microphone
GDU150
Attractive and elegant in design, this gooseneck microphone allows for smooth noise-
less microphone positioning. Outstanding speech intelligibility, feedback rejection,
user sound isolation, high sound pressure capability, and low sensitivity to breath/pop
noise. Features a superior shock-mount system to reject handling and transmission
noise, a built-in locking push-button on/off switch, and an integral multi-layer
breath/wind filter. (19-1/4" H x 1-1/4" dia., 1 lb. )
UHF Wireless Microphone System
UDMS16HH, UDMS16BP
Bogen’s Wireless Microphone Systems offer users the freedom to
move around while speaking. System choices consist of a 16-channel
PLL-synthesized UHF Receiver with either a handheld microphone
or lavaliere microphone and body-pack transmitter.
• 10-1/4" long, fully flexible neck
• Durable all-metal case with non-glare black finish
• Rugged, reliable construction
• Cardioid pickup pattern
• Dynamic element
• 500-ohm impedance
• Wide frequency response range of 100 Hz -12 kHz
• Sensitivity of -75 dB +/- 3 dB
Industrial Gooseneck Microphone
MGN19
Designed to stand up under the most strenuous handling conditions, this gooseneck is
extremely reliable and provides a natural crisp, highly-intelligible sound. Features four
conductor, two-shielded, permanently attached, synthetic jacketed cable, and a
DPDT push-to-talk button-operated sealed microswitch mounted on the microphone
housing. (23-1/2" H x 1-1/4" dia. (mic body), 1-1/4 lb.)
• 19" flexible neck with mounting flange
• Chrome-plated screen and gooseneck,
black Cycolac
®
cap and housing
• Durable, rugged construction
• Omni-directional pickup pattern
• Dynamic element
• 400-ohm impedance
• Frequency response is uniform from
50 Hz -12 kHz with 2 kHz boost
• Sensitivityof -76 dB +/-3 dB
• Sleek metal housing with internal antenna for optimum
aesthetics and durable long life
• Features a uni-directional neodymium dynamic cartridge
for optimum sound, maximum feedback rejection,
and minimal handling noise
• Audio mute switch allows convenient audio muting while
leaving the transmitter "ON"
• LED indicator: Unit "ON", and "Low Battery Alert"
• Convenient, economical operation with AA alkaline
or NiMH batteries (2x)
UHT16 Handheld Microphone
• Audio mute switch allows convenient audio muting while
leaving the transmitter "ON"
• LED indicator: Unit "ON", and "Low Battery Alert"
• Locking 3.5mm mini-jack provides secure connection for
removable microphone
• Convenient, economical operation with AAA alkaline
or NiMH batteries (2x)
• Headset microphone (BCHM) is also available.
UBP16 Body-Pack w/Lavaliere Microphone
• Offers 16 user-selectable frequencies in UHF 470-510 MHz
band; 120 dB dynamic range; operation up to 500 feet
line-of-sight
• DigiTRU Diversity™ for maximum range and dropout
protection, full LED indicators, both 1/4" unbalanced
and XLR balanced outputs, Tone Squelch™ for locking
out potential interference, noiseless transmitter ON/OFF
switching, and level control for unbalanced output
• Half-rack receiver design with front panel dual antennas,
powered by wall power adapter
• Optional rack mount accessories available for single-
or dual-rack mounting (RPK89/RPK90)
UDR16 16-Channel PLL-Synthesized
UHF Receiver
UHT16
UDR16
UHT16
UDR16
UBP16
BCHM
UDMS16HH
includes:
• UHT16 Handheld Mic
• UDR16 UHF Receiver
UDMS16BP
includes:
• UBP16 Body-Pack
& Lavaliere Mic
• UDR16 UHF Receiver
Accessory
• BCHM Headset Mic
