HANDHELDS
DESKTOPS
SPECIALTY
0˚
180˚
330˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
30˚
-60
-70
dB
-80
-90
-100
-110
20
1
K Hz
200 2
K
20K
Frequency Response, Magn dB re 1 V/ BAR
0°
180°
Handheld Public Address Microphone
HDO100
Delivers smooth, professional sound. Provides a custom-tailored balanced
response to complement any vocal style and timbre for singing, speech, or instru-
ment sound reproduction. Uniform pickup of sound from all directions with no
deterioration in frequency response. Clean, clear reproduction with minimal
ambient sound. Low sensitivity to handling noise and stage vibrations. Slim design
provides optimum handling and control. Features an internal rubber shock isolation
system, a rigid low noise cable mount system, and a lockable silent on/off reed
switch. (6-1/2" D x 1-1/2" dia., 1 lb.)
• Durable all-metal zinc case w/rubberized black finish
• Omni-directional pickup pattern
• Moving coil dynamic element
• 500-ohm impedance
• Frequency response range of 70 Hz -15 kHz
• Sensitivity of -72 dB +/- 3 dB
Professional Handheld Stage Microphone
HDU250
Performs professionally in acoustically demanding environments. Capable of pro-
jecting vocals with remarkable clarity and power. Excellent gain before audio feedback,
reduced pickup of unwanted signals, increased frontal sensitivity, low sensitivity to
breath/pop noise, and high sound pressure capability without distortion. Features
an efficient shock-mounted Neodymium capsule that prevents handling and trans-
mission noise, a rigid low-noise cable-mount system, a multi-layer breath/wind
filter, and a lockable silent on/off reed switch. (7" D x 2" dia., 1 lb.)
• Durable all-metal zinc case w/rubberized black finish
• Heavy, rugged reliable construction
• Cardioid pickup pattern
• Moving coil dynamic element
• 250-ohm low impedance
• Wide frequency response range
of 50 Hz - 18 kHz
• Sensitivity of -72 dB +/- 3 dB
0˚
180˚
330˚ 30˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
-60
-70
dB
-80
-90
-100
-110
20
1
K Hz
200 2
K
20K
Frequency Response, Magn dB re 1 V/ BAR
0°
180°
Handheld Stage Microphone
HDU150
Provides crisp, clear sound in any environment. Wide frequency range ensures
audio richness. Minimal audio feedback, excellent sound balance and tolerance,
reduced pickup of unwanted signals, increased frontal sensitivity, and low sensitivity
to breath/pop noise. Features a rubber shock-mount system for attenuation of
handling and cable noises, a rigid low noise cable mount system, and a lockable
silent on/off reed switch. (6 -1/2" D x 1-1/2" dia., 1 lb.)
• Heavy all-metal zinc case w/rubberized black finish
• Durable ball-shaped construction
• Cardioid pickup pattern
• Dynamic element
• 500-ohm impedance
• Frequency response range of 70 Hz - 15 kHz
• Sensitivity of -70 dB +/- 3 dB
-60
-70
dB
-80
-90
-100
-110
20
1
K Hz
200 2
K
20K
Frequency Response, Magn dB re 1 V/ BAR
0°
180°
0˚
180˚
330˚ 30˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
-60
-70
dB
-80
-90
-100
-110
20
1
K Hz
200 2
K
20K
0∞
180∞
Frequency Response, Magn dB re 1 V/ BAR
Desktop Paging Microphone
MBS1000A
This dual-impedance desktop microphone provides natural,
highly intelligible sound that is smooth and peak free. With
its sleek and stylish design, the MBS1000A is operated with a
simple push-to-talk bar (lockable) or lift-to-talk operation
(defeatable) for activating the microphone and external equip-
ment. Features 7 feet of four-conductor, 2-shielded cable; an
impedance selector switch; and four molded
non-skid, non-marring “feet”.
(4-3/8" W x 9-3/8" H x 5-7/8" D, 1.25lb.)
• Cardioid pickup pattern
• Dynamic element
• Rubberized finish
• Impedance: Hi-Z, 50k ohms; Lo-Z, 500 ohms
• Wide frequency response range of 45 Hz - 15 kHz
• Sensitivity: Hi-Z, -52 dB +/- 3 dB;
Lo-Z, -72 dB +/- 3 dB
• For industrial and commercial, public
address & paging applications
0˚
180˚
330˚ 30˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
-60
-70
dB
-80
-90
-100
-110
20
1
K Hz
200 2
K
20K
Frequency Response, Magn dB re 1 V/ BAR
0°
180°
Dynamic Desktop Microphone
DDU250
High-quality slim, compact desktop microphone with gooseneck posi-
tioning flexibility for sound reinforcement applications. Exudes excellent
speech and intelligibility. Cuts through noisy backgrounds of live miking
situations and large gatherings. Effective control of feedback, reduced
ambient handling noise, and low sensitivity to breath and popping
sounds. Features a push-to-talk switch, a push-to-lock
switch, a hard-wired 10-foot long 5-conductor cable,
and a wire-mesh wind filter. Table stand with on/off
switch.
(4-1/4" W x 18-1/4" H x 6-1/4" D, 3-1/2 lb.)
• 16" sturdy, flexible neck
• Rugged metal die cast base w/shock mount
• Matte black finish
• Cardioid pickup pattern
• External contact closure outputs
• Moving coil dynamic element
• 500-ohm impedance
• Wide frequency response range
of 100 Hz -12 kHz
• Sensitivity of -76 dB +/- 3 dB
0˚
180˚
330˚ 30˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
0˚
180˚
330˚ 30˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
-60
-70
dB
-80
-90
-100
-110
20
1
K Hz
200 2
K
20K
Frequency Response, Magn dB re 1 V/ BAR
0°
180°
Professional Boundary Microphone
SCU250
Full, rich reproduction of voice and music in a low-profile
design. Perfect for applications where minimum visibility is
required, or where a handheld microphone might be impractical
to use. Low sensitivity to thumping noise, excellent user sound
isolation, feedback rejection, and reduced room reverberation.
Excellent clarity for multiple microphone applications.
(2-3/4" W x 3/4" H x 3-1/4" D, 1 lb.)
• Heavy-duty metal case with matte black finish
• Cardioid pickup pattern
• Electret condenser element
• Phantom power operated (9-52V DC)
• 250-ohm impedance
• Frequency response range
of 20 Hz -18 kHz
• Sensitivity of -58 dB +/- 3 dB
0˚
180˚
330˚
60˚
300˚
90˚
270˚
240˚
210˚
120˚
150˚
30˚
-50
-60
dB
-70
-80
-90
-100
20
1
K Hz
200 2
K
20K
Frequency Response, Magn dB re 1 V/ BAR
0°
180°
Professional Overhead Hanging Mic
WCU250
High-quality sound reinforcement from a low-profile, compact,
lightweight hanging microphone. Adjust metal hanger to angle
in any direction. Ceiling-mount design allows for overhead
pickup of groups. Accurate and dependable. Clear, crisp sound
with full, rich reproduction of voice and music. Excellent off-
axis rejection, no peaks, reduced handling noise sensitivity,
high SPL handling capacity, and superior feedback control
with no acoustic or electrical phase anomalies or audio band
resonance. Low mass diaphragm. Features a high-tensile cable
with mini XLR output plug. (1-1/4" D x 1/2" dia., 5 ounces.)
• Stainless steel, adjustable black hanger
• 20-foot long cable
• Matte black finish
• Cardioid pickup pattern
• Electret condenser element
• Phantom power operated (9-52V DC)
• 250-ohm impedance
• Wide frequency response range of 50 Hz - 18 kHz
• Sensitivity of -65 dB +/- 3 dB
