Chapter 12 Field-Replaceable Unit Guide
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN2
Step 7 Reattach the Ethernet and signal cables according to your temporary markings.
Do not attach the camera hoods at this time.
Step 8 Power on the system by completing the steps in the “Powering On the System” section on page 12-1.
Step 9 Perform the camera adjustment procedure and, if required, refocus and realign the camera.
See the “Setting Up the Cameras” section on page 10-6 for more information.
Step 10 Re-attach the camera hood and lens hood.
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN2
Required Information, Tools, and Equipment
To replace a display, you need the following information, tools, and equipment:
• Release Notes for Cisco TelePresence System, Release 1.4, OL-12074-05
• Cisco TelePresence System Release 1.4 Administrator’s Guide, OL-13676-03
Uncrating and unpacking:
• Claw hammer or small pry bar
• Large Phillips screwdriver
• * Tin snips
• * Pallet jack or hand cart (for moving components)
• * Safety gloves
• * Safety glasses
• * Box cutters
Cisco TelePresence 3200 Structure, Accessory, and Adjustment Assembly:
• Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
Tip A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
• Manual screwdrivers, Phillips and flat head types
• Metric wrenches, 10 to 15 mm
• 9/64-inch Allen wrench (supplied with speakers)
• 0.9mm Allen wrench for camera lens adjustments (if the lens uses a thumbscrew no tools are
required)
• Level
• Masking tape
• * Tie wraps
