5-5
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Display Shelf Assembly
Parts List
Step 3 Attach the center Display shelf
Figure 5-3 Center Display shelf
Note Refer to Figure 5-1 to see the hardware used to attach the center Display shelf to the left Display
shelf.
201149
2
13
13
