show csm
Voice over IP for the Cisco AS5800 31
The following is sample output from the Cisco AS5800 for the show csm voice command:
5800# show csm voice 1/8/19
shelf 1, slot 8, port 19
VDEV_INFO:slot 8, port 19
vdev_status(0x00000401):VDEV_STATUS_ACTIVE_CALL.VDEV_STATUS_HASLOCK.
csm_state(0x00000406)=CSM_OC6_CONNECTED, csm_event_proc=0x60868B8C, current
call thru PRI line
invalid_event_count=0, wdt_timeout_count=0
watchdog timer is not activated
wait_for_bchan:False
pri_chnl=(T1 1/0/0:22), vdev_chnl=(s8, c19)
start_chan_p=0, chan_p=62436D58, call_id=0x800D, bchan_num=22
The calling party phone number =
The called party phone number = 7511
ring_no_answer=0, ic_failure=0, ic_complete=0
dial_failure=0, oc_failure=0, oc_complete=1
oc_busy=0, oc_no_dial_tone=0, oc_dial_timeout=0
remote_link_disc=0, busyout=0, modem_reset=0
call_duration_started=3d16h, call_duration_ended=00:00:00,
total_call_duration=00:00:00
Table 1 explains the fields contained in both of these examples.
Table 1 show csm voice Field Descriptions
Field Description
slot Indicates the slot where the VFC resides.
shelf/slot/port Specifies the T1 or E1 controller.
dspm/dsp/dsp channel Indicates which DSP channel is engaged in this call.
dsp Indicates the DSP through which this call is established.
slot/port This is the logical port number for the device. This is equivalent to the DSP
channel number. The port number is derived from:
(max_number_of_dsp_channels per dspm=12) * the dspm # (0-based) +
(max_number_of_dsp_channels per dsp=2) * the dsp # (0-based) +
the dsp channel number (0-based).
tone Indicates which signalling tone is being used (DTMF, MF, R2). This only
applies to CAS calls. Possible values are:
—mf
—dtmf
— r2-compelled
— r2-semi-compelled
— r2-non-compelled
