Introduction
Your I+ME NetPorty II
Version 1.03
1-2
1.1 Your I+ME NetPorty II
The NetPorty II is an improved portable network
adapter. It is designed to connect devices with RS232
or Centronics interface to the CAN bus. With its features
it is an ideal general purpose hardware for industrial and
automotive analyzes and diagnostics.
With NetPorty II you can visualize bus-traffic and
configure components within a CAN network. It enables
you to transfer software from or to control components.
The data can be exported to readable by standard PC
programs like Excel. In this way the user can generate
statistic diagrams, etc. to analyze the CAN
communication.
In the I+ME standard software you can set bus specific
values. For transmitted or received data it is possible to
assign fix display to one CAN message.
In addition to the above mentioned features you can
transfer your own programs to NetPorty II by the use of
the RS232 link. The download utilities are included as
well as sample programs.
The NetPorty II can optionally be equipped with an
UART for automotive diagnosis. In this case it is a
converter RS 232 or Centronics to ISO 9141 (K-Line).
Working with the parallel port is 2..5 times faster as the
serial port access. The speed depends on the PC
speed.
