Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone 1-800-654-3545.
• PART NUMBER
• NAME OF ITEM
• PART DESCRIPTION
• MODEL NUMBER
Part Numbers
Key Model No.
No. Description CF750ORB00
* Hanger Pack, Consisting of: 761655-50
1 Hanger Bracket Assembly (1) —
2 Hanger Ball (1) —
3 Downrod, Long 8” (1) —
* Parts Bag, Containing: 763304
4 Pin, Clevis (1) —
5 Clip, Hairpin (1) —
6 Connector, Wire, 12 Ga. (3) —
7 Stud, Threaded,
#8-32 x 1-1/4” (2) —
8 Lockwasher, External Tooth
#8-32 (2) —
9 Knob, Knurled #8-32 (2) —
10 Screw, Washer Head,
M5 x 6mm (16) —
11 Screw, Pan Head,
M5 x 12mm (11) —
12 Lockwasher, M5 (11) —
13 Screw, Serrated Head,
M4 x 10mm (4) —
14 Kit, Balancing (1) —
15 Cover, Ceiling (1) 763286-ORB
16 Scroll, Decorative Upper (1) 763303-ORB
17 Cover, Coupling (1) 763287-ORB
18 Housing, Assembly, Upper (1) 763288-ORB
19 Glass, Housing Center (1) 763290
20 Harness, Wiring (1) 763302
21 Light Kit Plate Assembly (1) 763307-ORB
22 Glass, Lower (1) 763296
23 Washer, Rubber (1) 763312
24 Jamnut, Hex 1/8-27 NPS (1) —
25 Nut, Finial (1) 763297-ORB
26 Flange Set (full set for one fan) 763298-ORB
27 Blade Set (full set for one fan) 763300
28 Downrod, Short (4.5”) 761631-37
29 Receiver, SW105 Remote Control (1) 762401
30 Transmitter, Remote Control (1) 763306
— Owner's Manual (1) BP7333
Repair Parts Listing
17
