In order for the auxiliary
A/C-heater controls to function,
the driver’s auxiliary A/C-heater
control must be set to REAR.
The instrument panel climate
controls must be on in order for
the auxiliary A/C-heater to operate.
When the auxiliary A/C-heater
control is set to FLOOR, airflow
only occurs from the third row
seat floor vent located in the
driver’s side rear quarter trim
panel.
When the auxiliary A/C-heater
control is set to PANEL, airflow
occurs from the overhead 2nd and
3rd row vents.
Turn the fan speed control knob to
the desired speed.
WARM PANEL FLOORCOOL
REAR
OFF
HI
HI
COOL WARM
OFF
PANEL
FLOOR
DEF
FLR
& DEF
PANEL &
FLOOR
LO
LO
OFF
HI
