29
ITEM NO. PART NO. DESCRIPTION QTY
1 34101363 Lower deck 1
2 34115365 Inlet connector1 1
3 33127302 Nut 1
4 34124319 Inlet Nut 1
5 34213301 O-ring 1
6 33166307 Inlet nut connector 1
7 31901301 Water inlet lter 1
8 32229301A Ring 2
9 32308316A Washer 2
10 31901363 Wheel 2
11 33201363 Wheel shaft 2
12 34904363 Water inlet hose 1
13 33911302 Clamp 2
14 33902365 Spring 1
15 34125363 Water inlet connector 1
16 34204365 O-ring 1
17 34117365 Water outlet connector1 1
18 33302365 U pin 3
19 31112363 High-pressure connection pipe 1
20 34226316A Motor seal 1
21 34210303A Rubber bushing 5
22 34101316A Capacitance junction box 1
23 3290675 Spring washerφ4 4
24 32903301A Washer 4
25 32202316A Screw 3
26 34118316A Junction box 1
27 34109363 switch box bracket 1
28 34206363 Switch box seal 1
29 34110363 Switch box 1
30 32211316A Screw 6
31 36302301A Switch 1
32 34105363 Separating panel 1
33 32204301A Screw 1
34 32912301A Washer 1
35 36504301A R terminal 1
36 34201316A O-ring 1
37 36488301 Capacitance 1
38 36401363 Connecting wire 1
39 36501301 Female connection terminal 7
40 36503301 Terminal bushing 6
41 34901363 Net bag 1
42 31125363 Motor and pump ASSY 1
PARTS LIST
