Drum
REF PART # DESCRIPTION REF PART # DESCRIPTION
17 PSS03 SET SCREW 1/4-20 X 3/8 82 PSS51 SET SCREW 5/16-24 X 1/2
23 PB02 HEX BOLT 1/4-20 X 5/8 85 PW02 FLAT WASHER 3/8
25 PN05 HEX NUT 1/4-20 86 PLN01 LOCK NUT 3/8-16
26 P0459026 SPRING PLATE 88 P0459088 COMP SPRING 24-20-8MM 63L
27 P0459027 ADJUST PLATE 89 PB51 HEX BOLT 1/4-20 X 3/8
42 PK34M KEY 5 X 5 X 20 89-1 PW06 FLAT WASHER 1/4
70 P0459070 PRESSURE ROLLER 90 P0459090 BRACKET
71 P0459071 SANDING DRUM 92 P0459092 HOOK & LOOP SANDBELT
73 PR08M EXT RETAINING RING 19MM 92-1 P0459092-1 HOOK & LOOP DRUM COVER
74 P1066062 BUSHING 94 P0459094 DRUM PULLEY
81 P1066081A PILLOW BLOCK BEARING 98 PVA36 V-BELT 4L360
