HP Uninterruptible Power System R1500 XR Models User Guide 1-3
Front Panel
The front panel of the UPS is shown in Figure 1-1.
2 31
Figure 1-1: Front panel configuration
1 Battery compartment
2 Control buttons
3 LED display
For detailed information on using the control buttons and LED indicators, refer to the section,
“Front Panel Controls and LED Indicators,” in Chapter 2.
