Interface ports
The printer has five ports: two EIO slots and three ports for connecting to a computer or a
network.
5
1
2
3
4
1 EIO slot 2
2 Network connection (for models that include an embedded HP Jetdirect print server)
3 EIO slot 1
4 IEEE 1284B-compliant parallel port
5 USB port (compatible with USB 2.0 full- and high-speed devices)
Accessory lights
Use the following table to interpret the status lights on the optional 500-sheet stacker or 500-
sheet stapler/stacker accessory.
Light Meaning for accessory
Solid green ● The accessory is on and ready.
Solid amber ● The accessory is experiencing a hardware
malfunction. (See
Understanding accessory
lights for the stacker and stapler/stacker.)
Blinking amber ● The accessory has an error condition that
needs attention. (See
Understanding
accessory lights for the stacker and stapler/
stacker.)
Off ● The printer might be in PowerSave mode.
Press any button on the printer control panel.
● The accessory has an error condition that
needs attention. (See
Understanding
accessory lights for the stacker and stapler/
stacker.)
