9-11

Traffic/Security Filters and Monitors

Filter Types and Operation

Figure 9-7. Example of the show filter Command

Using the IDX value in the show filter command, we can see how traffic is

filtered on a specific port (Value).The two outputs below show a non-

accounting and an accounting switch port.

ProCurve(config)# show filter

Traffic/Security Filters

IDX Filter Type | Value

--- ------------ + -------------------

1 Source Port | 2

2 Source Port | 3

3 Source Port | 4

4 Source Port | 5

5 Source Port | 6

6 Source Port | 8

7 Source Port | 9

8 Source Port | 12

20 Source Port | 24

21 Source Port | 25

22 Source Port | 26

23 Source Port | 7

24 Source Port | 10

25 Source Port | 11

26 Source Port | 1

Indicates the port number or port-

trunk name of the source port or trunk

assigned to the filter.

An automatically assigned index

number used to identify the filter for

a detailed information listing. A filter

retains its assigned IDX number for

as long as the filter exists in the

switch. The switch assigns the

lowest available IDX number to a new

filter. This can result in a newer filter

having a lower IDX number than an

older filter if a previous (source-port

or named source-port) filter deletion

created a gap in the filter listing.
