DesignJet 750CPlus (D-size)
HP Parts Reference Guide™
Paper Drive Parts
Bail
C7770-60273 Bail assembly - Mounting strip assembly for the starwheel mount assemblies (Not included) - Extends width of plotter (D
-size)
Cable
250
C3195-60102 Ribbon cable with ferrite - Has 5 pin (F) connectors - 16.5cm (6.5 inches) long
Gear
251
C1633-40019 Overdrive gear cluster
Gear Assembly
252
C4705-60089 Clutch / overdrive gear assembly
Motor
253
C3195-60009 Bail stepper motor - Used to drive the bail assembly
Motor/Gear
254
C4705-60068 Paper (X-axis) drive motor (includes helical drive gear - NOTE: motor and gear are only sold as a set
Overdrive Assy
255
C4705-60121 Overdrive assembly (D) - Includes roller, enclosure, bushings
Platen
256
C3195-60173 Entry Platen Assembly - Cover/guide that is next to the paper drive (Platen) roller
Roller
257
C4699-60042 Paper drive (Platen) roller assembly - Long gear driven roller - Includes roller and mark encoder
Sensor
258
C3190-60140 Media sensor mechanical assembly - Includes, edge measuring and secondary levers, media sensor and holder
Starwheel Mount
259
C4713-60035 Starwheel mount assembly - Includes cover, body, spring and two starwheels
Paper and Other Media
Film (Clear)
C3876A Clear film (4 mil) - 61cm (24in) x 22.9m (75ft) roll
Film (Glossy)
C1829A High-gloss white film - A1 size (59.4cm x 84.1cm) - 125 sheets
NO LONGER SUPPLIED
C1827A High-gloss white film - Architectural D size (24 x 36-inches) - 100 sheets
NO LONGER SUPPLIED
C3886A High gloss white film (4 mil) - 61cm (24in) x 30.5m (100ft) roll
Film (Matte)
51642C Polyester matte film - B size (11 x 17-inches) - 40 sheets
NO LONGER SUPPLIED
51642A New Part for 51642C
51642G Polyester matte film - D size (22 x 34-inches) - 40 sheets
NO LONGER SUPPLIED
51642A New Part for 51642G
51642H Polyester matte film - A1 size (59.4cm x 84.1cm) - 40 sheets
NO LONGER SUPPLIED
51642A Polyester matte film - 61cm (24in) x 36.6m (120ft) roll
51642J Polyester matte film - Architectural D size (24 x 36-inches) - 40 sheets
NO LONGER SUPPLIED
51642A New Part for 51642J
